SigCon001-10

Isolated 4–20 mA input to 4–20 mA output signal isolator.

Overview

INS_3200 is a compact RFDIS controller board built for reliable field automation and industrial applications. With a high-performance STM32F407VGT6 Cortex-M4 processor and a comprehensive set of communication interfaces, it enables flexible connectivity with sensors, controllers, and industrial equipment.

Specifications

Technical specifications.

Input: 4-20mA
Output: 4–20 mA
Accuracy: 0.1% FS
Linearity: 0.1% FS
Isolation: 3.0kVDC for 65s
Ripple & noise: < 30 mVp-p
Dimensions: 23 × 100 × 115 mm
Enclosure: Polyamide (PA66)
Weight: 150 g

Full ratings, pin mapping and wiring are in the datasheet.

Features

Compact Din rail Mounting
4-20mA signal input
4-20mA Signal output
Isolated available 1, 2 & 4 channel
High accuracy of 0.1% FS
High linearity of 0.1% FS
Loop power no external voltage required
Isolation test voltage 3.0kVDC for 65s
High reliability, Low cost compact design, Convenient to Use
Rugged Durability

Applications

PLC Signal Isolation
Industrial Controller Interfacing
4–20 mA Signal Isolation
Two-Wire Field Device Integration
Industrial Automation Systems
Process Control Systems
Analog Signal Transmission
Multi-Channel Signal Isolation
Field Instrumentation
Controller-to-Field Device Isolation
